HammerTek
SMART ELBOW®

Includes: Deflection Elbows, Pipe Elbows, and Tubing Elbows.
HammerTek SMART ELBOW® for Pneumatic Conveying Systems to Prevent
Four Problems Caused by All Other Elbows.

*Images Courtesy Of HammerTek. All Rights Reserved.

Includes:
Deflection Elbows,
Pipe Elbows,
and Tubing Elbows.

HammerTek SMART ELBOW® for Pneumatic Conveying Systems to Prevent
Four Problems Caused
by All Other Elbows.

*Images Courtesy Of HammerTek. All Rights Reserved.

wear1

PREVENT wear

and failure when

conveying abrasives

streamer2

PREVENT formation

of streamers, angel hair

and snake skins

breakage3

PREVENT breakage

and dusting of fragile

materials

plugging

PREVENT plugging

and build-up

*Images Courtesy Of HammerTek. All Rights Reserved.

Problem

Wear and failure when conveying abrasives such as sand, glass, alumina or mineral filled plastic pellets incur never-ending costs of replacement elbows, labor and downtime

Cause

Abrasives hit the outside radius of conventional impact elbows at high speed, continually wearing through the elbow wall.

Solution

SMART ELBOW® Deflection Elbow
from HammerTek® ends problems by eliminating impact and frictional heat

*Images Courtesy Of HammerTek. All Rights Reserved.

*Images Courtesy Of HammerTek. All Rights Reserved.

Problem

Formation of streamers, angel hair and snake skins when conveying pelletized resins and compounds causes downstream quality problems

Cause

Pellets skidding against the outside radius of conventional elbows create friction and heat, melting pellet surfaces, forming streamers.

Solution

SMART ELBOW® Deflection Elbow
from HammerTek® ends problems by eliminating impact and frictional heat

Problem

Breakage and dusting of fragile materials
such as pet food, coffee beans or grains, decrease product quality, consistency and salability while increasing waste.

Cause

Friable materials hit the outside radius of conventional impact elbows at high speed, degrading the material and generating fines.

Solution

SMART ELBOW® Deflection Elbow
from HammerTek® ends problems by eliminating impact and frictional heat

*Images Courtesy Of HammerTek. All Rights Reserved.

*Images Courtesy Of HammerTek. All Rights Reserved.

Problem

Plugging and build-up
when conveying heat- and pressure-sensitive materials prone to build-up.

Cause

Materials skidding against the outside radius of conventional elbows create friction and heat, causing product build-up.

Solution

SMART ELBOW® Deflection Elbow
from HammerTek® ends problems by eliminating impact and frictional heat
